Product Description

Transformers are important devices therefore increasing the importance oil. Transformer oils are lost quality in time. Consisting of moisture in the oil causes sludge and acid after a short time with a oxidation of air.

With transformer oil regeneration (treatment), electrical life are brought equivalent in new transformer oil. Transformer oil regeneration process can be eliminate acid, moisture, gas, sediment,fitler particles from the oil with the thermo-vacuum system and improve the quality.

Features:

1). Metallic Weather Proof Enclosure With Gas Springs

2). Germany Leybold Vacuum Pump

3). Schneider Electric Apparatus

4). CTP Three Screw Low Noise Oil Pump (Germany Allweiler Technology)

5). ABB Electric Motors

6). Omron Intelligent Temperature Controller

7). High Precision Digital Display Flow Meter

8). Siemens PLC + Touch Screen (easy operation)

9). Siemens Micromaster 420 Frequency Inverter (Adjust Oil Flow Rate)

Advantages:

Comparing with single stage transformer oil purifier, Series ZYD oil purifier can increase the effectiveness more than three times, more quickly and completely dewater, degas, remove particles to get higher dielectric strength. This equipment can be used as independent vacuum source with the functions of vacuum drying and vacuum oiling for the electric plants.

Parameters		Unit	ZYD-30	ZYD-50	ZYD-100	ZYD-150	ZYD-200	ZYD-250	ZYD-300
Flow Rate		L/H	1800	3000	6000	9000	12000	15000	18000
Working Vacuum		MPa	-0.08 ~ -0.099
Working Pressure		MPa	≤ 0.3
Temp Range		℃	20 ~ 80
Power Supply			380V/ 50Hz/ 3Phase( As per your requirement)
Working Noise		Db	60 - 85 (Depended on the configurations)
Heating Power		KW	30	30	48	72	72	90	120
Total Power		KW	33	35	55	80	82	102	135
Inlet/Outlet Diam		MM	25	32	42	50	50	60	60
Weight		KG	450	550	750	950	1200	1850	2000
Size	Length	MM	1450	1450	1750	1850	1950	2050	2150
	Width	MM	950	1000	1250	1300	1350	1400	1450
	Height	MM	1700	1750	1950	2000	2050	2100	2150
AFTER TREATMENT
Dielectric Strength		KV	≥ 70
Water Content		PPM	≤ 5
Gas Content		%	≤ 0.1
Particle Size		μ	≤ 3

transformer oil purifier, transformer oil purification, transformer oil filtration, transformer oil treatment, transformer oil dehydration, transformer oil regeneration, transformer oil filtering, transformer oil purifying, transformer oil processing, transformer oil reclamation, transformer oil reconditioning, transformer oil handling
