Trailer-mounted & Double-stage vacuum Transformer oil filter/ filtration Machine

Get Latest Price

Payment Type:: L/C, T/T

Incoterm:: CIF

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 15 Days

Transportation:: Ocean

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	100 Sets/Month
Supply Ability:	100 Sets/Month
Payment Type:	L/C,T/T
Incoterm:	CIF
Certificate:	ISO9001:2015
Transportation:	Ocean

Product Description

According to user's requirements, we developed Series ZYM mobile insulating oil purifier, this machine is mainly used for dealing with unqualified transformer oil, switch oil, mutual inductor oil,, it can rapidly remove water, gas, particles from oil, improving insulating oil's properties. Besides all functions of series ZYD, the best advantage of ZYM is that can move long distance working in field.

Features:

1.Mobile(trailer) type, completely closed structure, waterproof, dustproof, move easy.

2. Installation of car tyres,Bridge shock absorber, braking system and steel welding of entire trailer guarantee 60km/h speed.

3. Dealing with unqualified insulating oils, rapidly remove water, gas, particles from oil

4. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies

5. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.

6. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.

7. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.

Advantages:

Mobile (trailer) type, completely closed structure, waterproof, dustproof, it can move long distance working in field.

P4061911

Parameters		Unit	ZYD-30	ZYD-50	ZYD-100	ZYD-150	ZYD-200	ZYD-250	ZYD-300
Flow Rate		L/H	1800	3000	6000	9000	12000	15000	18000
Working Vacuum		MPa	-0.08 ~ -0.099
Working Pressure		MPa	≤ 0.3
Temp Range		℃	20 ~ 80
Power Supply			380V/ 50Hz/ 3Phase( As per your requirement)
Working Noise		Db	60 - 85 (Depended on the configurations)
Heating Power		KW	30	30	48	72	72	90	120
Total Power		KW	33	35	55	80	82	102	135
Inlet/Outlet Diam		MM	25	32	42	50	50	60	60
Weight		KG	450	550	750	950	1200	1850	2000
Size	Length	MM	1450	1450	1750	1850	1950	2050	2150
	Width	MM	950	1000	1250	1300	1350	1400	1450
	Height	MM	1700	1750	1950	2000	2050	2100	2150
AFTER TREATMENT
Dielectric Strength		KV	≥ 70
Water Content		PPM	≤ 5
Gas Content		%	≤ 0.1
Particle Size		μ	≤ 3

transformer oil purifier, transformer oil purification, transformer oil filtration, transformer oil treatment, transformer oil dehydration, transformer oil regeneration, transformer oil filtering, transformer oil purifying, transformer oil processing, transformer oil reclamation, transformer oil reconditioning, transformer oil handling
