High Efficiency Vacuum Dehydration Turbine Oil Purifier

Get Latest Price

Payment Type:: L/C, T/T

Incoterm:: CIF

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 15 Days

Transportation:: Ocean

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	100 Sets/Month
Supply Ability:	100 Sets/Month
Payment Type:	L/C,T/T
Incoterm:	CIF
Certificate:	ISO9001:2000
Transportation:	Ocean

Product Description

TY vacuum turbine oil purifier mainly be used for purifying unqualified turbine oil, especially for serious emulsion turbine oil, it can quickly and efficiently break emulsification, separate water, gas, particles from oil. So that makes sure quality of treated oil to achieve new oil's standard, ensure whole turbine system work safely. This equipment use a special polymer materials as filter medium combined with vacuum separating technology to break emulsification, dewater, degas, remove acid and particles, make the badly turbid turbine oil becomes clear transparent. Series TY is a perfect turbine oil purifier for live line work; also it can purify low viscosity hydraulic oil and lube oil.

Features:

1. Special polymer materials as filter medium with the functions of broken emulsion, dewatering, removing particles

2. Duplex-Stereo film evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil.

3. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technology.

4. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.

5. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.

6. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.

7. Work online with stream turbine, hydraulic turbine.

Parameters		Unit	TY-10			TY-20	TY-30	TY-50	TY-100	TY-200	TY-300
Flow Rate		L/H	600			1200	1800	3000	6000	12000	18000
Working Vacuum		Mpa	-0.06 ~ -0.095
Working Pressure		Mpa	≤ 0.4
Temp Range		℃	40 ~ 70
Power Supply			380V/ 50HZ/ 3P (as per request)
Working Noise		Db	≤ 65 - 80
Heating Power		KW	12		15		24	30	45	72	84
Total Power		KW	14		17		26	33	48	81	97
Inlet/Outlet Diam		MM	25		25		25	32	42	50	60
Weight		KG	400		450		500	600	800	1050	1500
Size	Length	MM	1280		1350		1350	1400	1500	1600	1800
	Width	MM	750		900		950	950	1000	1350	1400
	Height	MM	1450		1450		1500	1600	1650	1800	1850
AFTER PURIFICATION
Demulsification Value				Min	≤15 (GB/F 7305)
Cleanliness				NAS	NAS 1638 Class 5 - 7
Water Content				PPM	≤ 100
Gas Content				%	≤ 0.1
