Gas engine oil recycling, oil purifier, YFL Lubtication oil separator and purifier system(oilpurifiermelody@126.com)

Application It mainly applys to separator all kinds of light oil, high viscosity’s lubrication oil to restore the treated oil color. Especially the manufacture of the bearing and gear could purifier the coal oil for air which contains all kinds of lubrication oil: such as, anti-rust oil, cut oil etc, this equipment could be separatored efficiently the water, mechanical impurity, precipitate and causticity from the waste oil. (Separatored rate 100%) ※ Feature： 1. This equipment combination the absorption separator, rotatonal flow separator, electrolyze separator, neutrality separator, deep decolor, mechanical purification to be one. 2. It has following features: such as low cost of the purification, easy operation, the excellent effective of decolor and so on. The color difference is keep within 1%. Main technical data Item Unit Technical specification YFL-50 YFL -100 YFL-150 YFL -200 YFL -300 Flow rate L/min 50 100 150 200 300 Working vacuum Mpa -0.05 ～ -0.098 Work pressure Mpa ≤0.5 Work temperature ℃ 0 ～ 100 Working noise dB(A) ≤78 Work voltage V 50Hz380V three phase four wire system Total electric power KW 50 53 55 60 77 Total electric power (Light oil) KW 1.6 2 3 .3.5 4 Weight kg 1500 1800 2200 2750 3100 Weight （Light oil） Kg 2000 2300 2600 3000 3500 Size mm 根据用户场地设计 Water capacity % trace～none Mechanical impurity % 0．005～none kinematic viscosity mm2/s GB/T265-88 Flash ponit (Open ponit) ℃ GB/T3536 Acid Value mgOH/g GB/T259 Color SH/T Remark: The size and weight in the above form will adjust as per customer’s requirement so the actual size and weight will inform later. Contact: Melody Chongqing Zhongke oil purifier manufacture Co., Ltd Email: melody080926@126.com oilpurifiermelody@126.com Hotmail: melody080926@hotmail.com Tel: 0086-023-68655099 68655266 68661766 Fax: 0086-023-68174166 http://melody080926.ec51.com http://oilpurifierzk.ec51.com http://melody080926.tradeprince.com/
