Heavy Fuel Oil Separator and Filtration Machine (TYA)

Heavy Fuel Oil Separator and Filtration Machine (TYA)

$9800.00 - $16800.00/Set/Sets

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Transportation:: Ocean, Air

Port:: Chongqing, Shanghai, Shenzhen

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	100 sets per month
Supply Ability:	100 per month
Payment Type:	L/C,T/T,Western Union
Incoterm:	FOB,CIF
Certificate:	ISO 9001/CE
HS Code:	90308990
Transportation:	Ocean,Air
Port:	Chongqing,Shanghai,Shenzhen

Product Description

ASSEN Automatic Heavy Fuel Oil Separator and Filtration Machine with PLC Control System (TYA Series)

Application:

ASSEN Automatic Heavy Fuel Oil Separator and Filtration Machine with PLC Control System (TYA Series) is catered to reclaiming unqualified hydraulic oil whereby the removal of emulsified water and dirt particles is very important steps of waste oil treatment. This machine can extend the life of your heavy fuel oil, reduce machine downtime and less equipment maintenance. It is widely used in petroleum, chemical, mining, metallurgy, electric power, transportation, machinery manufacturing, railway etc. It can promote your efficiency and save your cost, meanwhile, it is important to our environment. This machine can also purify other waste oil like hydraulic oil and turbine oil.

Features of ASSEN Automatic Heavy Fuel Oil Separator and Filtration Machine with PLC Control System (TYA Series)

1.Longer the life of your oil and equipment by two or three times oil pass

2.Clean your entire system

3.Remove unwanted gases from the oil

4.Rejuvenate varnished oil

5.Flush your system of contaminants

6.Friendly to our environment

7.Free your system of emulsified water

8.Save you money by avoiding costly shutdowns and new oil purchases

9. Reduce the times of machine shutdown

10.Remove impurities and/or particulates from the oil

11.Minimize danger to the turbine, hydraulic, and lube equipment

12.save your cost of human consumption

ASSEN Automatic Heavy Fuel Oil Separator and Filtration Machine with PLC Control System (TYA Series)'s Technical Parameters

Item		Unit	TYA-10	TYA-20	TYA-30	TYA-50	TYA-100	TYA-150	TYA-200	TYA-300
Flow Rate		L/min	10	20	30	50	100	150	200	300
Vacuum Degree		MPa	-0.06 ~ -0.095
Working Pressure		MPa	≤0.4
Temperature		ºC	0 ~ 100
Power Supply			3phrase,50Hz, 380V(or as needed)
Working Noise		dB(A)	≤75	≤75	≤75	≤78	≤78	≤78	≤80	≤82
Heating power		kW	36	40	45	72	80	90	120	135
Total power		KW	38	42	47	75	87	101	135	147
Inlet/outlet caliber		mm	25	25	25	32	42	50	50	60
Weight		Kg	450	550	600	750	850	1000	1200	1500
Dimension	Length	mm	1500	1500	1500	1600	1750	1900	1900	2100
	Width	mm	1000	1050	1050	1150	1250	1600	1700	1700
	Height	mm	1200	1600	1600	1700	1800	1950	2000	2100
Parameter After Purification
Demulsification value		min	New oil ≤15min, running oil ≤30min
Water Content		PPM	≤50
Gas Content		%	≤o.1
Cleanness		NAS	≤6 grade

Optional models for your needs
1.Portable Oil Filter Cart,Hydraulic Oil Cleaning Machine,Movable Oil Filtration Equipment
2.Explosion-proof BT4/CT4 vacuum Lube Oil Filter Machine,Lubricating Oil Purification System
3.TYA-I Phosphate Ester Fire-resistant Hydraulic Oil Filtration Plant

ABOUT US

Chongqing Assen Power Equipment Co.,LTD, which is professional in design, manufacture, sale of oil purification equipment, relevant testing instruments and provide comprehensive filtering solution, owns advanced production lines and sophisticated detection equipment, first-class R & D staff, professional workers and High-quality sales and service teams

Our Product: Double Stage Transformer Oil Purification System, Vacuum Lubricating Oil Purification, Vacuum Turbine Oil Conditioner, Portable Oil Purifier, Singe Stage Insulating Oil Purifier, Lubricating Oil Purification, Water Oil Separator, Light fuel Oil Purifier, and Fully-auto Dielectric Oil Tester, Turn ratio Tester, Acid Tester, Moisture Detector, Interfacial Tension Tester, etc.
Our Service: special filter technology consulting and solutions sector; fast after-sale service feedback system, well-trained service engineer; hands-on training and large-scale equipment operation myrmidon; regularly visit system, CRM customer relationship management system; rapid Filter wearing parts and spare parts supply system.

ASSEN warrants the plant supplied under this specification against defects in material and workmanship under normal use and service for a period of twenty-six (26) months from the date of shipment or twenty-four (24) months after the start-up of the system. ASSEN's obligation under this warranty is limited to repairing or furnishing, a similar part to replace any part, which was proven to be defective within the warranty period.
1. We customize the machine to your requirements.
2. We have more than 20 years of export experience.
3. We offer our customers high-quality products at a competitive price.
4. We offer our customers excellent after-sales service.
5. We are not satisfied until our customers are satisfied.
