Cummins KTA50 Marine Engine For Sale

Get Latest Price

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Transportation:: Ocean, Land, Air, Express

Port:: Shanghai, Shenzhen, Chongqing

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China.Chongqing
Productivity:	10000
Supply Ability:	10000
Payment Type:	L/C,T/T,D/P,D/A,Paypal,Western Union
Incoterm:	FOB,CFR,CIF,FCA,DDP,DDU,Express Delivery
Certificate:	ISO9001
HS Code:	8511509000
Transportation:	Ocean,Land,Air,Express
Port:	Shanghai,Shenzhen,Chongqing

Product Description

The performance of Cummins KTA50-M2 Marine engine is excellent, especially suitable for harsh Marine environments, its reliability and durability is now used in a wide range of recreational vessels, including superyachts and support vessels, meet both IMO requirements and Tier 2 emission standards.

Engine Power: 1800/1900/2100rpm

Engine Model: KTA50-M2

Product Category：Cummins Engine
Application Type：Cummins Marine engine

KTA50-M2 Marine Engine Technical Specification
Engine Model	KTA50-M2
Rating Type	Continuous
Rated Engine Power	1900hp /1342kW
Rated Engine Speed	1900rpm
Peak Engine Torque@ 1500 rpm	4859 lb. H ft. / 6588 NHm
Cylinders	16
Aspiration	Turbocharged & Aftercooled
Compression Ratio	13.9:1
Piston Speed	1876 ft/min / 9.5 m/sec
Displacement	50L
Bore*Stroke	159*159mm
Fuel System	PT pump
Fuel Consumption at Rated Speed	80.2gal/hr / 303.6 l/hr
Approximate Fuel Flow to Pump	141gal/hr / 533.7 l/hr
Intake Manifold Pressure	54in. Hg / 183kPa
Intake Air Flow	2599 cfm / 1227 l/sce
Heat Rejection to Ambient	4464 BTU/min / 78 kW
Size-Engine Only	350018002200mm
Weight (Dry) - Engine Only	5200kg
Minimum Idle Speed Setting	650rpm
Normal Idle Speed Variation	±25rpm
High Idle Speed Range Minimum	1860rpm
High Idle Speed Range Maximum	1972rpm
Standard Thermostat Operating Range (Start to Open - Full Open)	82°C-94°C
Optional Configuration	According to the Cooling Type( Keel Cooling, Circulating Cooling,etc.) Heat Exchanger, Expansion Tank, Sea Water Pump, Control System, Remote Control System.
