2mm-100mm Fiberglass Rod, Glass fiber Rod(0.079inch,2mm)
-
$8.001-9999 Others
-
$0.5010000-5999999 Others
-
$0.43≥6000000 Others
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shen Zhen Port, Qingdao, Dalian Port
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|---|
| Productivity: | 20 tons/daily |
| Supply Ability: | 20 tons/daily |
| Payment Type: | T/T,Paypal,Alibaba,West Union,Alipay,etc |
| Incoterm: | FOB,CIF,EXW,DDP,DDU,Express Delivery |
| Certificate: | CE,ISO,Test Report,etc. |
| HS Code: | 7019909990 |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shen Zhen Port,Qingdao,Dalian Port |
Product Description
Product Description
Composite (Glass fiber yarn)materials using glass fiber and its products (glass cloth, tape, felt, yarn, etc.) as reinforcing products and synthetic resin as the matrix (Fiber glass rod) products.
Fiberglass rod is a composite products that uses glass fiber and its products (glass cloth, tape, felt, yarn, etc.) as reinforcing materials and synthetic resin as the matrix material.
It means that one material cannot meet the requirements of use, and two or more materials need to be combined together to form another material that can meet people's requirements, that is, composite products. For example, although a single type of glass fiber has high strength, the fibers are loose and can only withstand tensile force, but cannot withstand bending, shearing and compressive stress. It is not easy to be made into a fixed geometric shape and is a soft body. If they are bonded together with synthetic resin, they can be made into various hard products with fixed shapes, which can withstand not only tensile stress, but also bending, compression and shear stress.
| Fiberglass Rod | |||||||
| Diameter | Weight | Diameter | Weight | ||||
| mm | inch | g/m | lb/ft | mm | inch | g/m | lb/ft |
| 2 | 0.079 | 6 | 0.004 | 17.5 | 0.689 | 481 | 0.323 |
| 3 | 0.118 | 14 | 0.009 | 18 | 0.709 | 509 | 0.342 |
| 3.2 | 0.126 | 16 | 0.011 | 19 | 0.748 | 567 | 0.381 |
| 4 | 0.157 | 25 | 0.017 | 20 | 0.787 | 628 | 0.422 |
| 5 | 0.197 | 39 | 0.026 | 22 | 0.866 | 760 | 0.511 |
| 6 | 0.236 | 57 | 0.038 | 24 | 0.945 | 905 | 0.608 |
| 6.35 | 0.25 | 63 | 0.043 | 25 | 0.984 | 982 | 0.66 |
| 7 | 0.276 | 77 | 0.052 | 25.4 | 1 | 1013 | 0.681 |
| 7.5 | 0.295 | 88 | 0.059 | 26 | 1.024 | 1062 | 0.714 |
| 8 | 0.315 | 101 | 0.068 | 28 | 1.102 | 1232 | 0.828 |
| 8.5 | 0.335 | 113 | 0.076 | 30 | 1.181 | 1414 | 0.95 |
| 9.5 | 0.374 | 142 | 0.095 | 32 | 1.26 | 1608 | 1.081 |
| 10 | 0.394 | 157 | 0.106 | 35 | 1.378 | 1924 | 1.293 |
| 11 | 0.433 | 190 | 0.128 | 36 | 1.417 | 2036 | 1.368 |
| 12 | 0.472 | 226 | 0.152 | 38 | 1.496 | 2268 | 1.524 |
| 12.7 | 0.5 | 253 | 0.17 | 40 | 1.575 | 2513 | 1.689 |
| 14 | 0.551 | 308 | 0.207 | 45 | 1.772 | 3181 | 2.137 |
| 15 | 0.591 | 353 | 0.237 | 50 | 1.969 | 3927 | 2.639 |
| 15.7 | 0.618 | 387 | 0.26 | 50.8 | 2 | 4054 | 2.724 |
| 16 | 0.63 | 402 | 0.27 | 76 | 2.992 | 9073 | 6.097 |
| 16.5 | 0.65 | 428 | 0.287 | 100 | 3.937 | 15708 | 10.555 |
| If there are any differences in parameters, staff will inform you during consultation | |||||||
It (glass rod) (Fiberglass cloth)can be seen that the meaning of FRP refers to reinforced plastics with glass fiber as reinforcing material and synthetic resin as binder. It is called glass fiber strengthed plastic abroad. AS the development of my country's fiberglass industry, the plastic-based reinforcing materials have expanded from glass fiber to carbon fiber, boron fiber, aramid fiber, alumina fiber and silicon carbide fiber. Undoubtedly, reinforced plastics made of these new fibers , are some very high performance fiber-reinforced composite materials, which cannot be summarized by the common name of fiberglass. Considering the historical origin and development, fiberglass composite materials are usually used, so this name is more (glass fibre)comprehensive.
