Qingling 100p Refrigerated Truck
- Min. Order:
- 1 Vehicle
- Min. Order:
- 1 Vehicle
- Transportation:
- Others
Your message must be between 20 to 2000 characters
Contact Now| Payment Type: | Others |
|---|---|
| Transportation: | Others |
Refrigerated truck transportation is a transportation method that uses refrigeration equipment (refrigerated trucks, refrigerated insulation boxes, dry ice, etc.) to store items at low temperature and constant temperature during the transportation process to ensure the stability of product quality.
|
Technical parameters of the entire vehicle |
|||
|
Product trademark |
Qingling brand |
Announcement batch |
377 |
|
product name |
refrigerated truck |
Model |
QL5040XLCBUHAJ |
|
Total mass (Kg) |
4495 |
Tank volume (m3) |
|
|
Rated load capacity (Kg) |
1155 |
External dimensions (mm) |
5995x2070x2960 |
|
Curb weight (Kg) |
3210 |
Cargo compartment size (mm) |
4095x1900x1800 |
|
Rated passenger capacity (person) |
|
Total mass of quasi trailer (Kg) |
|
|
Approach angle/departure angle (°) |
24/16 |
Front/rear suspension (mm) |
1015/1620 |
|
Axle load (Kg) |
1805/2690 |
Maximum speed (km/h) |
105,115 |
|
notes |
1. The net power of the engine is 87kW, the engine model is 4KH1CN6LB, and the fuel consumption value is 11.3L/100km; When the 4KK1N6SD engine is optional with the chassis, the net power is 95kW, the fuel consumption value is 11.3L/100km, and the VIN is LWLDMMYYG; When the 4KB1-TCG60 engine is installed with the chassis, the net power is 94kW, the fuel consumption value is 10.2L/100km, and the VIN is LWLDMFMG; 2. The top of the car is closed and cannot be opened; 3. This car allows the optional installation of a right side single door; 4. Side protection material: steel plate Q235, connection method: bolted to the crossbeam of the carriage; Rear protection material: steel plate Q235, plate thickness 2.5mm, connection method: The rear protection bracket is connected to the rear end of the longitudinal beam of the frame with bolts. The size of the rear protection section is 139 × 50 (mm), and the ground height is 490mm; 5. The vehicle is equipped with a hydraulic brake system on the chassis. The corresponding relationship between the ABS and its controller model/manufacturer is: APG3550500A/Zhejiang Asia Pacific Electromechanical Co., Ltd., CM4YL/Guangzhou Ruili Kemi Automotive Electronics Co., Ltd; When installing a pneumatic braking system with the chassis, the corresponding relationship between the ABS and its controller model/manufacturer is CM4XL-4S/4M/Guangzhou Ruili Kemi Automotive Electronics Co., Ltd; 6. This car allows for the installation of different front panels, combined lighting fixtures, and grilles in the driver's cab along with the chassis, as well as the option to install widened rearview mirrors, regular rearview mirrors, signs, etc; 7. Allow the installation of different units with equivalent power from different manufacturers; 8. Optional right side double door is allowed. The curb weight includes spare tire, rubber pad, 90% fuel, coolant, lubricant, etc. The weight of the car body is 1107Kg, and the corresponding material of the floor/side panel is PU+fiberglass composite plate, with a thickness of 85/70 (mm). 10. Hydraulic tailboard is allowed. The horizontal length of the hydraulic tailboard when retracted is 280mm, and the weight of the tailboard is 350kg. The rear protection is a cylindrical structure, with a cross-sectional size of Ф 114mm, material thickness 2.0mm, ground height 420mm. |
||
|
Chassis technical parameters |
|||
|
Chassis Model |
QL1040BUHAY |
Chassis brand |
Isuzu |
|
manufacturing enterprise |
Qingling Motors Company Limited |
Address |
|
|
number of axles |
2 |
Number of tires |
6 |
|
wheelbase |
3360 |
||
|
Tire Size |
7.00R16LT 8PR |
||
|
Number of steel plate springs |
3/3+2,8/6+5 |
||
|
Front wheelbase (mm) |
1377,1504 |
Rear wheelbase (mm) |
1425,1525 |
|
fuel type |
diesel oil |
Emission standards |
GB3847-2005,GB17691-2018National VI |
|
Engine model |
Engine Manufacturer |
Displacement (ml) |
Power (Kw) |
|
4KH1CN6LB |
Isuzu (China) Engine Co., Ltd
Isuzu (China) Engine Co., Ltd
Isuzu (China) Engine Co., Ltd
Isuzu (China) Engine Co., Ltd |
2999 |
88 |
