CE,ISO Approved Transformer Oil Insulation Oil Tester,IEC156,Simple operation, high degree of automation

Specifications

CE,ISO Approved Transformer Oil Insulation Oil Tester,IEC156,Simple operation, high degree of automation

Product Description
BDV Insulating oil tester, is a comprehensive index for insulating oil., which is special for testing insulating oil`s dielectric strength. IIJ-II Automatic oil tester is designed according to international standard of IEC156. Apply large integrate circuit, new type I/O interface, LCD displayer, and adopt industrial single chip as controller, which combined with special testing and anti-jamming technologies that greatly improve the tester`s performance.

Product Feature
Features:

1. Simple operation, high degree of automation (just press a button)

2. Using the menu management, easy to understand the input parameters

3. Can store 99 groups oil sample test data to facilitate future access to and print, test data can be stored in power off state for 10 years.

4. The system clock in the power off state can continue to run.

5. Through the RS232 port with a software upgrade or with the PC, on-line detection.

6. Anti-interference ability

7. Detection with high precision 8. Small size, light weight, easy operations

Product Specification/Models
Technical Parameters:

1. Power supply: AC220V±10%, 50Hz

2. Output voltage: 0~80KV(60KV---80KV)

3. Capacity: 1.2KVA(1.6KVA --2.0KVA)

4. Speed of pressure rise: about 2KV/S

5. Voltage test precision: ±3%

6. Breakdown sensitivity: <2KV

7. Wave difference: <=3% 8. Time of breakdown: <=10ms

9. Working condition temperature : 0C---40C humidity : The biggest comparatively humidity85%

10. Reserve circumstance temperature : -20C---60C humidity : The biggest comparatively humidity75% Working altitude: <1500m (if over 1500m can be designed specially)

11. Dimension: 480mm*460mm*460mm

(oil purifier, oil purification, oil filtration, oil recycling, oil treatment, oil regeneration, oil restoration, oil filtering, waste oil disposal, oil reclaiming, waste oil management, energy saving, oil reconditioned, oil reconstituted, oil restituting, oil recovering ,oil filtration, oil filter, petroleum machine, oil tester, oil analyzer, testing equipment)

Our oil tester/ analyzer:
Series IIJ-II Insulating oil breakdown strength tester(oil BDV tester)

Series HTJS-H Insulating oil dielectric tester (dielectric loss tester for insulating oil)

Series HTJS-V Tan-Delta Tester (anti-jamming dielectric loss tester for HV electrical equipment)

Series TP-3A Water content tester/ moisture sensor
Series TPV-8 Viscosity analyzer
Series TPC-2100 Flash point analyzer (close cup)
Series TPO-2100 Flash point analyzer (open cup)
Series CL-3 Interfacial tension analyzer
